Carbide Lined Guide Bush – Drawn Type
Skillcrafts Industries
Precision Guiding for Swiss-Type CNC Machining
Carbide Lined Guide Bushes – Drawn Type are designed to provide accurate guidance and support for bar material during Swiss-type CNC machining. The carbide-lined guiding surface offers wear resistance while maintaining consistent support of the workpiece during machining.
The drawn-type design is commonly used on sliding-headstock CNC machines where stable material guidance is important for precision turning applications
Key Features
- Carbide-lined guiding surface for improved wear resistance
- Drawn-type design for Swiss-type CNC applications
- Precision guiding of bar material during machining
- Consistent workpiece support close to the cutting area
- Suitable for round, hexagonal and square profiles, depending on configuration
- Available in different dimensional configurations to suit machine and application requirements
Applications
Carbide Lined Guide Bushes – Drawn Type are used in:
- Swiss-type CNC turning
- Sliding-headstock machining
- Long and slender component machining
- High-volume precision turning
- Bar-guiding applications requiring stable support
A guide bush supports the bar material near the cutting zone, helping maintain controlled guidance during machining
Why Carbide Lining?
The carbide lining provides a wear-resistant guiding surface, making it suitable for applications where the guide bush is exposed to continuous movement of bar material. This can help maintain the guiding condition over extended machining use.
Drawn Type Guide Bush
The drawn type configuration is designed for adjustable guide-bush applications. Technical configurations can vary by machine model, guiding diameter, overall length, thread and angle.
Technical Specifications
Specifications should be selected according to the machine model, required guiding diameter, workpiece profile and machining application. Typical catalogue dimensions include guiding diameter, total length, thread, angle and capacity for round, hexagonal and square profiles.
For exact Skillcrafts Industries sizes, part numbers and dimensions, use the approved product drawing/catalogue before publishing the specification table.
Custom Requirements
Requirement → Engineering → Machining → Inspection → Delivery
If a standard configuration does not match your machining requirement, share your machine model, drawing or component details with Skillcrafts Industries so the required guide-bush configuration can be discussed.
